Cassandra [ /kəˈsændrə/ ] was a research project led by Dan Hughes. It set out to address two critical issues that could arise in a sharded network, specifically Radix’s forthcoming Xi'an release:
What happens if a subset of validators cease processing transactions, leading to a liveness failure?
How can validator sets be dynamically adjusted in case of liveness failures?
Overview
Cassandra was a collaboration between an unofficial organization called Radix Labs, the University of California Davis’ ExpoLab, and community members running nodes.
Part of the project was to create a decentralized test version of Twitter with the ability to tip users in $XRD.
Etymology
Cassandra was named after the mythological Trojan priestess who would accurately prophesy to her master, Apollo, but was never believed.
Background
Cassandra evolved out of Dan Hughes’ Flexathon project in January 2021. A technical demonstration using Twitter data was premiered on Twitch on March 13th, 2021. 40% of the project was described as ‘new code’.
Implementing the Xi'an upgrade to a fully sharded network is necessary for Radix to scale to “support the needs of the $400 trillion global financial market”. However, transitioning to an explicitly sharded system introduces significant security, decentralization, and liveness challenges. Sharding lets the ledger process transactions in parallel across many shards. It also raises a question: how can validators on different shards stay in consensus on the global state?
To study these issues, Hughes started the Cassandra research project from scratch, setting aside existing consensus algorithms like Cerberus and HotStuff that Radix currently uses. The objective was to take a blue sky approach to determine what components are necessary to create a secure, decentralized, and live sharded environment.
Question 1: Liveness in Sharded Networks
In a sharded environment, a subset of validators across different shards can stop processing transactions. Parts of the network then stall, which is a liveness failure. This can happen unintentionally due to technical issues or intentionally by adversaries looking to disrupt the network.
Liveness failures are especially problematic in networks like Radix that use deterministic consensus algorithms to achieve transaction finality. These algorithms require approval from 2/3 of validators to finalize transactions. If 1/3 or more validators stop participating, the network cannot make progress.
Existing consensus algorithms lacked strong provisions to ensure liveness in sharded environments. Hughes wanted the Radix network to keep weak liveness during partial liveness failures, so that its live parts could keep making progress.
Question 2: Dynamically Adjusting Validator Sets
In decentralized networks, validator sets are determined algorithmically through ‘sybil protection’ mechanisms like staking. However, liveness failures may require proactively removing non-participating validators from the active set. This raises a challenge: How can validators be removed without centralized control of the ledger? In addition, any validator set adjustment process could be vulnerable to malicious validators looking to attack the network without needing 1/3 of the total stake. Hughes wanted a way to adjust validator sets in response to liveness issues that adversaries could not manipulate to their advantage.
State Model
Cassandra exists on a fixed shardspace of 2^256 shards indexed on the Vamos database structure. Transactions are processed on a first-come, first-served basis and in parallel if the transactions use different inputs. The network scales linearly as more nodes are added.
Consensus
Cassandra used a hybrid probabilistic / deterministic consensus, where round leaders within shard groups are determined by proof of work. This provides flexibility to maintain liveness and safety under different network conditions. Cassandra incorporates elements of Cerberus, but is distinct from it.
Probabilistic Phase
The probabilistic phase is driven by a proof-of-work system. Validators who wish to propose the next set of transactions must solve a computational ‘puzzle’ to submit proposals. This makes the cost of submitting proposals proportional to computational power rather than stake.
If validators submit conflicting proposals, the ledger forks until 2/3 of the validators vote in favor of the canonical version. This allows the network to dynamically adjust relative voting powers and make progress even if 1/3 or more of validators are not participating.
A key advantage of Cassandra's probabilistic phase is that validators are rewarded with increased voting power on the network for providing useful proposals. This allows the network to recover from liveness failures by bringing in new validators. For example, if 50% of validators go offline, the remaining validators create proposals to make progress on their shard. As these proposals gain majority approval, the participating validators increase their voting power, which dilutes the weight of the offline validators. Over time, this allows the network to regain a 2/3 majority of participating stake needed to finalize transactions. The more stake that goes offline, the more time it takes for the network to ‘earn back’ enough voting power to resume finalizing transactions.
Deterministic Phase
Once 2/3 of validators agree on a proposal, the consensus process is determined by stake-weighted voting and provides finality on the accepted transactions.
Effectiveness
Maintaining Liveness
The probabilistic proposal phase provides an inherent weak liveness guarantee, even if 1/3 or more validators stop participating. As long as some validators continue submitting proposals, the network can continue building potential blocks. Bitcoin's Nakamoto consensus works in a similar way: the network keeps mining and extending the longest chain even if a large share of miners disappear. Progress is slowed proportional to the lost computational power, but the network continues converging on a canonical chain. In Cassandra, validators who continue participating will eventually converge around a common branch of proposals. This allows the network to continue making progress during liveness failures until enough validators regain participation to finalize transactions again.
Maintaining Safety
Cassandra's hybrid model maintains a high threshold for safety guarantees, even while providing liveness flexibility.
Attackers must overcome two hurdles to violate safety guarantees like double spends:
Gain majority control of proposing power to build fraudulent branches during the probabilistic phase. This requires large computational resources.
Acquire 1/3+ of voting power during the deterministic phase to finalize a fraudulent branch. This requires staking resources.
Attackers lacking either sufficient compute power or stake cannot unilaterally violate safety. The cost to attack both phases makes Cassandra more robust compared to pure probabilistic or deterministic consensus alone.
Advantages & Tradeoffs
Advantages
Cassandra provides several key advantages compared to traditional consensus algorithms:
Strong safety guarantees: Attackers face high costs to build fraudulent branches and finalize them.
Liveness guarantees: The network can make progress even with partial liveness failures.
Validator set shuffling: The network can adjust relative voting powers to recover from liveness issues.
Protection against attacks: Manipulating validator sets is costly due to the hybrid model.
Tradeoffs
Slower finality time: Cross-shard coordination introduces additional latency before finality.
Throughput vs finality: Faster finality requires more centralized shard configuration. Slower finality enables higher decentralization.
Complexity: Hybrid model is more complex than pure probabilistic or deterministic algorithms.
While Cassandra provides significant advantages, there are also tradeoffs to consider. The hybrid model requires more coordination which can introduce latency. However, it allows Radix to optimize for both decentralization and throughput.
The Cassandra research demonstrates that maintaining both liveness and strong safety guarantees in a highly decentralized sharding environment is possible. However, it requires balancing complex tradeoffs between latency, throughput, decentralization, and simplicity.
Ongoing Research and Development
The Cassandra research project has demonstrated promising solutions to core problems around implementing sharding for Radix. However, significant work remains to refine, optimize, and evaluate Cassandra for production use.
Optimizing the Protocol
While initial results are positive, improvements can be made to Cassandra to optimize latency, throughput, attack resistance, and efficiency. Areas of ongoing research include:
Reducing cross-shard coordination overhead
Optimizing networking and message passing between shards
Improving reward mechanisms and sybil resistance
Enhancing protection against long-range attacks
Minimizing wasted work during probabilistic proposal creation
Evaluating Production Viability
Before deploying Cassandra, extensive testing and peer review is required to validate the algorithm and analyze any potential vulnerabilities. Research areas include:
Formal verification of safety proofs
Security audits and attack simulation
Benchmarking throughput, latency, and efficiency
Testnet trials and experimental deployment
Continued alignment with academic state of the art
Integration into Xi'an
While Cassandra may not be deployed as-is, components of it could improve Radix's Xi'an implementation based on HotStuff. Analyzing which specific components can be integrated is an ongoing process.
The live effort to deliver Xi'an is now carried by hyperscale-rs, a community-built Rust implementation of the Hyperscale consensus mechanism that the Radix Foundation has described as evolving from the Cassandra research. It is positioned as the production candidate for the Xi'an mainnet release.
The Cassandra research provides a strong foundation, but remains a work in progress. By building on these concepts, Radix aims to develop production-ready solutions for secure, decentralized, and scalable sharding to meet the demands of global finance.
